RFSPICE: RF Circuit Design Software
About Product
RFSPICE is a comprehensive RF and mixed-signal circuit design and simulation tool featuring 25,000+ components, advanced device modeling, and support for both lumped and distributed networks. Powered by SPICE and XSpice engines, it enables accurate analysis of amplifiers, filters, transmission lines, and high-frequency systems in both time and frequency domains.
Streamlined user interface and quick schematic entry using a large set of keyboard shortcuts for generic parts and a versatile wiring tool
More than 25,000 analog, digital and RF parts including hundreds of realistic behavioral models for resistors, inductors and capacitors
A large selection of active device models (diode, BJTs, FETs, MOSFETs, MESFETS, operational amplifiers, etc.) with no less than six distinct MOSFET models including BSIM3 and BSIM4.
One-ports, two-ports, three-ports, four-ports, complex impedance, and other S-parameter-based devices
Import high-frequency models of capacitors, inductors, diodes, BJTs, JFETs, MOSFETs, MESFETs, from simple text files.
Ten types of physical transmission line models including microstrip, strip line, coplanar waveguide, coaxial lines, etc.
A large variety of RF generic components, such as Wilkinson power dividers, branch line and rat-race hybrid couplers, as well as physical line discontinuity models.
Streamlined user interface and quick schematic entry using a large set of keyboard shortcuts for generic parts and a versatile wiring tool.
More than 25,000 analog, digital and RF parts including hundreds of realistic behavioral models for resistors, inductors and capacitors.
A large selection of active device models (diode, BJTs, FETs, MOSFETs, MESFETS, operational amplifiers, etc.) with no less than six distinct MOSFET models including BSIM3 and BSIM4.
One-ports, two-ports, three-ports, four-ports, complex impedance, and other S-parameter-based devices.
Import high frequency models of capacitors, inductors, diodes, BJTs, JFETs, MOSFETs, MESFETs, from simple text files
Ten types of physical transmission line models, including microstrip, strip line, coplanar waveguide, coaxial lines, etc.
A large variety of RF generic components, such as Wilkinson power dividers, branch line and rat-race hybrid couplers, as well as physical line discontinuity models.
APPLICATIONS
Equipped with the Berkeley Spice 3F5 and Georgia Tech XSpice simulation engines and enhanced with RF multiport and transmission line models, RF.Spice can analyze a large variety of analog, digital, RF and mixed-mode circuits in both time and frequency domains.
Analyze lumped and distributed RF amplifiers, oscillators, filters and matching networks.
Import full-wave electromagnetic models of passive devices directly from EM.Cube.
Build new parts from your circuits and package them as reusable database devices or create unlimited user-defined parameterized sub circuit models
ANALOG TUTORIAL
EXPERIMENT NO. 01
Simple Voltage Divider Circuit
EXPERIMENTNO. 02
Time and Frequency Domain Analysis of an RLC FilterDIGITAL TUTORIAL
EXPERIMENT NO. 0
Examining Logic Gates
EXPERIMENT NO. 04
Analyzing a Sequential Logic Circuit -The SR Latch
EXPERIMENT NO. 05
Building a Shift Register Usin g D Flip-FlopsMIXED SIGNAL TUTORIAL
EXPERIMENT NO. 06
Analyzing Basic Mixed-Mode Circuits with Logic Gates
EXPERIMENT NO. 07
Designing D-A Converters
EXPERIMENT NO. 08
Designing a Digital Ramp Generator.RF TUTORIAL
EXPERIMENT NO. 09
AC Analysis of a Simple Transmission Line Circuit
EXPERIMENT NO. 10
Transient Analysis of a Simple Transmission Line Circuit
EXPERIMENTNO. 11
TransientAnalysis of a Simple Transmission Line Circuit
EXPERIMENT NO. 12
Analyzing Microstrip Lines & Discontinuities
EXPERIMENTNO. 13
Designing Lumped and Distributed Microstrip Lowpass Filters
EXPERIMENT NO. 14
Examining Coupled Transmission Lines
EXPERIMENTNO. 15
Designing Distributed Bandpass Filters Using Coupled Transmission Line Segments
EXPERIMENT NO. 16
Designing an RF Bipolar Junction Transistor Amplifier with Lumped Matching Networks
EXPERIMENTNO. 17
Impedance Matching Using Tuning Stubso
EXPERIMENTNO. 18
Analyzing a Distributed Amplifier Using an Imported RF BJT Model
EXPERIMENT NO. 19
Designinga Microstrip MESFET Amplifier
EXPERIMENT NO. 20
Time Domain Simulation of Generic RF Devices
